CH-E03C

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

Medical hospital beds are empowered by innovative design for nursing, providing multi-angle electric adjustment (including Trend-Lumber position and anti-Trend-Lumber position), adjustable height (38-78cm), and one-button safety functions, in compliance with EN 60601-2-52 standards. Its products adopt a lightweight framework and are equipped with an intelligent braking system, making them suitable for intensive care and home care scenarios. The product has passed ISO 13485 and EU CE certifications. The motor has a lifespan of up to 20,000 cycles and the noise is ≤45dB.

1. Core component certification ‌ : Combined with ISO 13485 medical device quality management system certification and EU CE safety standard.

2. Structural reinforcement design ‌ : Thickened steel frame (welding points pass 1.5 times load-bearing test) to ensure no risk of deformation or breakage over long periods of use.

3. Vibration damping and noise reduction structure ‌ : Rubber damping gaskets are added at the connection between the axle and the motor to reduce mechanical vibration conduction.

4. Static bearing capacity limit ‌ : Maximum static bearing capacity up to 250kg (dynamic bearing capacity 150kg), suitable for obese patients.

5. Safety protection design ‌ : Removable guardrail (height >40cm) and adjustable bed height can significantly reduce the risk of falling off the bed and relieve psychological unease.

Model NO.CH-E03C
Product Size:2130 * 1030 * (390-690) mm
Bedboard Size:2000*900mm
Safe working load250kg
Max. user weight:200kg
Voltage:Input: AC100~240V/50~60HZ
Back Up:0~75°
Leg Up:0~35°
Hi-low:390-690mm
Forward/Back-Tilting:/
Left/right-Tilting:/
Casters:5-inch Casters with  independent brake
Motor:DC linear motor
Control:Hand controller
Function:Calf board angle adjustment
Optional:Auto-regressive
Battery
  • Home Care‌: Provides 24/7 support for homebound seniors with limited mobility, easing family caregiving burdens.

  • ‌Post-Surgery Recovery‌: Safely assists patients recovering from fractures, spinal surgeries, or other procedures to accelerate rehabilitation.

  • ‌Chronic Condition Management‌: Reduces complication risks for long-term bedridden patients (e.g., stroke, paralysis, myasthenia gravis).

  • ‌Medical Facilities‌: Enhances care efficiency in hospitals, rehabilitation centers, and nursing homes.

Q: What are the key features of your care beds?‌

A: Multi-angle adjustment design (including backrest and leg elevation), anti-pressure sore air mattress system, lightweight frame with a maximum load capacity of 200kg.

‌Q: How to clean the mattress cover?‌

A: The TPU mattress cover is removable and washable. Use neutral detergent and avoid high-pressure water jets

Q: Where is your factory located? How can I visit you?

A: Our factory is located in medical devices production zone, Jizhou District, Hengshui City which is near the capital Beijing. You can fly to Beijing Capital International airport. Then take 1-hour high speed train to our city.

Q: Do you accept custom designs (OEM/ODM)?‌

A: Custom branding (logo imprinting) and personalized function designs are available upon submitting detailed requirements

Q: What are your payment terms?

A: T/T and L/C are the most common use payment terms. We also have rich experiences in D/P, DA and other payment terms. We will do what we can do to provide advantages.

Q: What is your QA/QC policy?

A: We have complete QA/QC regulations and strictly obey the regulations during all production procedures. Please ask for the regulations and cases from our sales directly.

Q: What's your warranty policy?

A: We provide life-time warranty for our products. Send us pictures or videos to the sales, we will provide after-sales services for you.
